Adding to the exciting and feature-rich HD block camera lineup is another dynamic model featuring 1280 x 720p HD resolution, the SONY FCB-EH3310. Clocking in with 20x zoom this camera offers outstanding picture quality for applications requiring vibrant, high-resolution images and flexibility. The SONY FCB-EH3310 utilizes a 1/4-type Exmor CMOS image sensor, boasting approximately 1,430,000 million effective pixels for extraordinary picture quality.
* 1280 x 720p High Definition: Ideally suited for Security monitoring applications
* Digital output (Y/Cb/Cr 4;2:2): The digital LVDS interface provides easy access for IP and Gigabit Ethernet applications.
* Temperature readout: The value of the internal temperature of the SONY FCB-EH3310 can be read out via the VISCA? protocl.
* Color enhancement: Ideally suited for low vision applications, new color enhancement options can make reading text and pictures less challenging
* Auto Wide-D Mode: The SONY FCB-EH3310 monitors the luminance differences within an image in high contrast environments and automatically switches Wide-D on and off accordingly.
* Auto ICR: The SONY FCB-EH3310 features a sensitive image sensor, ideal for day/night functions at less than 0.5 lux (F1.6, 50 IRE) with high-sensitivity mode on.
The SONY FCB-EH3310 Camera Specifications:
* Image Device: 1/4-type Exmore CMOS
* Effective Pixels: Approx. 1,430,000
* Digital Zoom: 12x (240x with optical zoom)
* Horizontal Viewing Angle: 55.9? (wide end) to 2.9? (tele end)
* Sync System: Internal
* Electronic Shutter: 1/1 to 1/10,000 s, total 22 steps
* White Balance: Auto, ATW, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto), One-push, Manual
* Gain: Auto/Manual/Max. Gain Limit (-3 to +28 dB, +2 dB step/total 16 steps)
* Wide Dynamic Range: Yes (30 fps)
* Privacy Zone Masking: Yes
* Character Generator: Yes (20 characters/line, max. 11 lines)
* Focus System: Auto (Sensitivity: normal, low), One-push AF, Manual, Infinity, Interval AF, Zoom Trigger AF, Focus Compensation in ICR On
* Picture Effects: E-flip, Nega Art, Black & White, Mirror Image, Color Enhancement
Video Output Specifications:
* Lens Value: 20x optical zoom, f=3.5 mm (wide) to 70.0 mm (tele), F1.35 to F3.4
* S/N Ratio: More than 50 dB
* Minimum Illumination: Less than 1.0 lx (F1.35, 50 IRE)
* Video Output: HD: Analog: Component (Y/Pb/Pr), Digital: Y/CB/Cr 4:2:2 via LVDS; SD: VBS
* Signal System: HD: 720p/59.94, 720p/50, 720p/29.97, 720p/25; SD: NTSC, PAL
* Camera Control Interface: VISCA? protocol (TTL signal level)
* Dimensions (W x H x D): 50.0 x 60.0 x 89.7 mm
* Weight: Approx. 240 g
* Operating Temperature: -5 to 60 degrees
* Storage Temperature: -20 to 60 degrees
* Power Consumption: 4.7 W (motors active) / 3.4 W (motors inactive)
